Ultrasonic Anemometer Wind Speed Direction Sensor Thermo Hygrometer Weather Station for Fishing Boat Yacht

Item Type: Ultrasonic Anemometer
Material: ABS
Wind Speed Range: 0~40m/s
Wind Speed Precision: ±2% (at 12m/s)
Resolution: 0.01 m/s
Measurement Unit: m/s
Wind Range: 0~359.9°
Resolution: 0.1°
Temperature Measurement Range: -20°C~+75°C
Temperature Measurement Accuracy: ±0.5°C (at 12m/s)
Temperature Resolution: 0.1°C
Measurement Unit: °C
Humidity Measurement Range: 10%~99.9%
Humidity Measurement Accuracy: ±2%RH (25°C)
Humidity Resolution: 0.1%RH
Pressure Measurement Range: 30000~ 110000 Pa
Altitude Measurement Unit: m
Altitude Measurement Range: +9000m~ 0m
Waterproof Grade: IP65
Working Temperature: 20°C~ +75°C
Storage Temperature: -30°C~ +80°C
Working Humidity: <5%~100%
Electromagnetic Compatibility: IEC60945
Input Source: 10.5 VDC ~ 40.5 VDC

Features

1、Function: The ultrasonic anemometer is used to measure wind speed and direction, temperature, humidity, air pressure and altitude.
2、Parameter: Two electrical output, RS485 and RS232, configurable baud rate up to 38400 (4800, 9600, 19200 and 38400), standard for NMEA sentences output.
3、Applicable Software: Can be used in PC with supplied PC software, and can also be used for Land Applications with ONWA Weather software.
4、Practical: Every channel output is isolated, support for Modbus protocol for industry use, and support for MDA sentence: Meteorological Composite (obsolete).
5、Easy Installation: No moving parts, does not need constant maintenance, four position sensor probe, 20m power harness, easy installation with mounting accessories.

Package List

1 x Ultrasonic Anemometer (With Mounting Base)

2 x Fuse

1 x Power Cable Harness (20m)

1 x Pack of Mounting Tools (9 Accessories)

1 x Instruction Manual
