Voltage Monitoring Sequence Relay Automatic Digital Reconnect Protector 108mm AC220V 50HZ

Item Type: Voltage Monitoring Sequence Relay
Material: Flame Retardant Nylon
Product Model: 1P+N
Working Current (In): 1-63A (adjustable)
Automatic Closing Delay Time: Less than or equal to 30s
Automatic Opening Delay Time: Less than or equal to 4s
Undervoltage Action Protection Time: 2-5s
Overvoltage Protection Time: 2-5s
Adjustable Range of Undervoltage: 145v-195v
Leakage Protection Setting Range: 10mA-99mA

Features

1、Have the functions of overload protection, short circuit protection, leakage protection, over and under voltage protection, and over voltage recovery.
2、Have the function of anti‑magnetic interference, with electric closing and no electric opening, prevent closing in the event of a fault, safe to use.
3、Have a fast closing function, avoid the adverse effects of the speed of the handle in the automatic reclosing and opening of the circuit breaker, thereby prolong the service life of the product.
4、The shell and parts are made of high flame‑retardant, high‑pressure‑resistant and impact‑resistant plastic.
5、Break down immediately after the relay is closed, which can be quickly opened to ensure the safety of electricity.
6、The contacts of the circuit breaker are always in a fully open or fully closed state, prevent the contacts from staying in the middle of the opening, or closing action due to faults.
7、A red control signal status light on the front of the relay, when the voltage reaches the rated closing voltage, the status light is on; when the voltage is less than the rated voltage, the status light is off to identify the current control state of photovoltaic reclosing.

Package List

1 x Voltage Monitoring Sequence Relay
