Product Overview
Features:
Specification:
Thread: G thread
Pressure regulating range (bar) : 5 (Min) ~20 (Max)
Differential pressure adjustment range (bar) : 2 (Min) ~5 (Max)
Factory setting (bar) : 14 (OFF/ON) ~16 (ON/OFF)
Maximum air tightness test (bar) : 33
Life of micro switch: 100,000 times
Weight: Approx.410g/14.5oz
Refrigerant: air, liquid and other non - corrosive media
Scope of application: control the pressure difference between liquid pipe and return pipe in water and oil series (air conditioning and other specific places)
Package list:
1 x Pressure Controller
1 x Install bracket
1 x instructions
4 x Screw
Specification:
Thread: G thread
Pressure regulating range (bar) : 5 (Min) ~20 (Max)
Differential pressure adjustment range (bar) : 2 (Min) ~5 (Max)
Factory setting (bar) : 14 (OFF/ON) ~16 (ON/OFF)
Maximum air tightness test (bar) : 33
Life of micro switch: 100,000 times
Weight: Approx.410g/14.5oz
Refrigerant: air, liquid and other non - corrosive media
Scope of application: control the pressure difference between liquid pipe and return pipe in water and oil series (air conditioning and other specific places)
Package list:
1 x Pressure Controller
1 x Install bracket
1 x instructions
4 x Screw
Features
1、SPC series pressure controllers are used for high and low pressure limit control of refrigeration equipment or automatic system air conditioning equipment.
2、Apply to air, liquid and other non - corrosive media.
3、Standard mounting bracket is provided for easy installation.
4、The SPDT switch ensures reliable contact switching.
5、The pressure bellows of the standard model are phosphor copper bellows and the pressure connection is made of brass. The bellows and the pressure connection for the ammonia refrigerant model are made of stainless steel
Package Weight and Dimension
| Weight | 0.94 lb |
| Width | 3.12 Inch |
| Height | 2.34 Inch |
| Length | 4.29 Inch |
