Product Overview
Item Type: X-Axis Linear Stage
Product Material: Aluminum alloy
Surface Treatment: Anodic oxidation treatment
Table Size: Approx. 80 x 80mm / 3.1 x 3.1in
Feeding Method: Knob type
Moving Amount (X distance): ± Approx. 30mm / 1.2in
Load: 20kg
Pitch: 1.5mm
Displacement of One Rotation of Knob: Approx. 1.5mm / 0.1in
Product Material: Aluminum alloy
Surface Treatment: Anodic oxidation treatment
Table Size: Approx. 80 x 80mm / 3.1 x 3.1in
Feeding Method: Knob type
Moving Amount (X distance): ± Approx. 30mm / 1.2in
Load: 20kg
Pitch: 1.5mm
Displacement of One Rotation of Knob: Approx. 1.5mm / 0.1in
Features
1、The main body adopt aluminum alloy, light weight and strong, friction‑resistant, quiet, scratch‑resistant, drop‑proof and corrosion‑resistant
2、Gear rotation handle control with high accuracy, smoothness, high load resistance, stable movement
3、Can be used for optical equipment, measuring devices, semiconductor manufacturing equipment, testing machines, microscopes, and photographic equipment
4、Also suitable for handling machines, processing machines, printing machines and others
5、Fine‑tuning X‑axis sliding table have stable structure, excellent performance and long service life
Package List
1 x X-Axis Linear Stage
Package Weight and Dimension
| Weight | 2.48 lb |
| Width | 3.9 Inch |
| Height | 2.73 Inch |
| Length | 9.75 Inch |
