Product Overview
Material: Aluminum Alloy, Plastic
Gross Weight: 224g / 7.9oz
Color: Black
Model: 120A ESC
Continuous Current and Burst Current: 120A, 860A
Motor Type: Sensorless brushless motor
4S Lipo or 12S NiMH:
1. Flat Car: 40xx motor KV<3000
2. Off Road Truck: 40xx motor KV<2500
6S Lipo or 18S NiMH:
1. Flat Car: 40xx motor KV＜2500
2. Off Road Truck: 40xx motor KV<2000
Internal Resistance: 0.00035ohm
Battery: 3~6S Lipo, 9~18S NiMH
BEC Output: 6.1V 5A or 7.4V 5A (switching mode)
ESC Size: Approx.57.5 x 45 x 37mm / 2.3 x 1.8 x 1.5in(without cable)
Suitable: for 1/8 RC car
Features
1、Compatible: Suitable for 1/8 RC cars, built in switch mode 6.1V 5A or 7.4V 5A (switching mode), compatible with high torsion and high voltage servos, easy to program, and compatible with pocket size program cards.
2、Superb Craftsmanship: Superb craftsmanship, exquisite circuit design for sensorless brushless motors, strong current resistance and excellent heat dissipation.
3、Waterproof Design: All weather waterproof and dustproof design, designed for RC model cars, with excellent starting, acceleration and linearity functions.
4、Multiple Protection Functions: Low voltage cut off protection for lithium or nickel batteries, ESC overheating protection, motor overheating protection, throttle signal loss protection, motor blocking protection.
5、Safe and Reliable: Made of premium aluminum alloy and plastic materials, fine workmanship, safe and reliable, durable, not easy to damage, long service life.
Package List
1 x 120A ESC
3 x Cable Wire
1 x Manual
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.51 Inch |
| Height | 1.95 Inch |
| Length | 5.46 Inch |
