Product Overview
Material: Electronic Components, Rubber
Product Color: Black
Weight: Approx. 25g / 0.9oz
Continuous Current: 12A
Instantaneous Current: 15A
BEC Type: Linear Regulator
BEC Output: 5V 2A
Number of Batteries: 2-3 Batteries
Applicable Model: Model Aircraft
Features
1、Throttle Signal Line: The twisted pair design of the throttle signal line can effectively reduce the crosstalk generated in the signal transmission and make the flight more stable.
2、Multi Rotor Controller: The main program dedicated to the multi rotor controller meets the various functional requirements of the multi rotor.
3、Full Protection: 12A brushless ESC has the performance of low voltage cutoff protection, over heat protection, throttle signal loss protection.
4、Good Performance: 12A continuous current,15A instantaneous current. BEC type is linear regulator, 5V 2A BEC output. The number of battery cells is 2‑3.
5、Applicable Model: The software is specially optimized to be compatible with disc engines. 12A brushless Esc with BEC is suitable for model aircraft.
Package List
1 x ESC
1 x Manual
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 4.29 Inch |
| Height | 0.39 Inch |
| Length | 5.07 Inch |
