Product Overview
Color: Black
Continuous Current: 30A
Peak Current: 35A-40A, 10 seconds.
Applicable battery: For 2-4S lipo.
BCE Output: 5V/2A
Applicable: Fixed wing aircraft for T rex 450, for V2 helicopter, for F450 small quad rotor UAV, etc.
Features
1、Safety Power On Function: When power on, no matter where the throttle rocker is, the motor will not start immediately to avoid injury.
2、Higher Accuracy: The throttle stroke calibration function can adapt to the difference of throttle stroke of different remote controllers and improve the linearity of throttle response.
3、Linear Adjustment: Smooth and stable speed control feel and speed regulation linearity, which also ensures higher working stability.
4、Low Voltage Protection: Reduce power or turn off output, and the default is to reduce power, effectively protecting the RC model.
5、The Input Terminal: The power input terminal adopts the electrolytic capacitor with ultra low impedance and large capacity, which greatly improves the anti interference ability.
Package List
1 x Brushless ESC
1 x User Manual
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.9 Inch |
| Height | 0.39 Inch |
| Length | 5.07 Inch |
