3650 4300kv Brushless Motor and ESC CNC Machining Waterproof Multiple Protection Brushless Motor with 60A ESC Kit

Item Type: Brushless ESC and Motor
Motor Parameters
Shell Material: Aluminum Alloy
Color: Green, Gold
Motor Size: Approx. 36 x 50mm/1.4 x 2.0in
KV Value: 4300KV
Wattage: 900W
Maximum Amperage: 69A
Maximum Speed: 50000
Shaft Length: Approx. 15mm/0.6in
Shaft Diameter: Approx. 3.175mm/0.1in
ESC Parameters
Shell Material: Plastic
Colour: Black
ESC Size: Approx. 50 x 35 x 30mm/2.0 x 1.4 x 1.2in
Continuous Current: 60A
Peak Current: 320A
Bce Output: 5.8V/3A
Applicable Battery (Not Included): 2-3s Li Po / 4-9s Ni Mh
Application: For 1/10 RC Remote Control Car

Features

1、Motor Features: Brushless motor and ESC adopts 4 extremely high torsion rotor design, with strong torsion and stable output power. Rich programmable items for a variety of RC tires and tracks.
2、CNC Machining: The brushless motor is CNC machined with 6061 T6 aluminum front and rear covers. High purity, high temperature resistant copper coils effectively provide high efficiency.
3、Durable: High toughness stainless steel output shaft, high accuracy high quality bearings make the motor super durable. The highest quality ESC components ensure efficient operation.
4、High Performance: High quality components make the components waterproof and dustproof, and durable. Strong resistive current capability and good heat dissipation.
5、Multiple Protection Functions: low voltage cut‑off protection, overheating protection, throttle signal loss protection. The internal timing can be easily changed to make the ESC suitable for a variety of motors.

Package List

1 x Motor

1 x ESC

1 x Manual
