Product Overview
Motor:
Shell Material: Aluminum Alloy
Color: Green and Gold
Product Size: Approx. 36x50mm/1.4x2.0in
KV Value: 3900KV
Wattage: 900W
Maximum Amperage: 69A
Maximum Speed: 50000
Shaft Length: Approx. 15mm/0.6in
Shaft Diameter: Approx. 3.175mm/0.13in
Connector: Approx. 4mm/0.16in Gold Banana Head
ESC:
Material: Plastic
Color: Black
Product Size: Approx. 50x35x30mm/2.0x1.4x1.2in
Continuous Current: 60A
Peak Current: 320A
BCE Output: 5.8V 3A
Applicable Battery (Without Battery): 2-3S Li Po,4-9S Ni Mh
Suitable for 1/10 RC Car
Features
1、STABLE MOTOR: Motor is designed with 4 extremely high torsion rotors, with strong torsion and stable output power. High toughness stainless steel output shaft and high accuracy high quality bearings create a super durable motor.
2、SAFE ESC: ESC has the best quality components to ensure efficient operation. Low voltage cut off protection, overheating protection, throttle signal loss protection.
3、WIDE APPLICATION: Motor ESC set can easily change the internal timing to adapt the ESC to various motors. Wide range of programmable items for various RC tires and tracks.
4、EXQUISITE CRAFTSMANSHIP: CNC machined 6061 T6 aluminum front and back cover of the set. High purity and high temperature resistant copper coils effectively provide high efficiency.
5、EXCELLENT PERFORMANCE: The set of high quality components make the components waterproof and dustproof, durable. Strong resistance current capability and good heat dissipation.
Package List
1 x Motor
1 x ESC
1 x Instruction Manual
Package Weight and Dimension
| Weight | 0.69 lb |
| Width | 3.12 Inch |
| Height | 2.34 Inch |
| Length | 3.9 Inch |
