Product Overview
Shell Material: Aluminum Alloy
Product Size: Approx. 50 x 10mm / 1.97 x 0.39in (without cable, base)
Shaft Diameter: Approx. 4mm/0.16in
Color: Silver
KV Value: 360KV
Maximum Continuous Current: 40A
Maximum Continuous Power: 750W
Recommended ESC: 20-40A
Recommended Battery: 2-6S Lipo
Recommended Propeller Size: 14-16 Inches
Application: RC Multi Axes Aircraft, Quadcopter
Features
1、STANDARD MOUNTING HOLES: Brushless motor features rear threaded mounting holes with 16mm/0.63in and 19mm/0.75in hole spacing for a variety of applications.
2、ANTI SHORT CIRCUIT: Use premium stator plate with 0.20mm/0.008in inner diameter and epoxy resin coated on the inner surface to prevent winding short circuit.
3、SAFE AND STABLE: The stator windings of brushless motors are fixed with high temperature adhesives to prevent them from shifting, pinching off or short circuiting.
4、PROFESSIONAL: 5010 brushless motor uses premium shielding and permanently lubricated ball bearings to support the motor shaft for safer use.
5、MULTIPLE APPLICATIONS: A total of 4 brushless motors are included for RC multi axes aircraft, quadcopter, designed for 14 to 16 inch propellers.
Package List
4 x Aircraft Brushless Motor
4 x Connector
32 x Screw
24 x Heat Shrink Tube
24 x Motor Connector
Package Weight and Dimension
| Weight | 0.98 lb |
| Width | 5.46 Inch |
| Height | 1.17 Inch |
| Length | 5.85 Inch |
