Product Overview
Condition: 100% Brand New
Item Type: Pointer DC Ammeter
Material: ABS
Model: 85C1-A DC 0~1MA
Accuracy Grade: ±2.5%
Insulation Resistance: > 20 m Ω / DC500V
Damping Time: Less than 4s
Use: Measuring line current
Installation Method: Suitable for vertical installation (except for special provisions)
Storage Temperature: -40℃~70℃
Operating Temperature: -20℃~40℃, relative humidity ≤85%
Size: As Pictures Show
Item Type: Pointer DC Ammeter
Material: ABS
Model: 85C1-A DC 0~1MA
Accuracy Grade: ±2.5%
Insulation Resistance: > 20 m Ω / DC500V
Damping Time: Less than 4s
Use: Measuring line current
Installation Method: Suitable for vertical installation (except for special provisions)
Storage Temperature: -40℃~70℃
Operating Temperature: -20℃~40℃, relative humidity ≤85%
Size: As Pictures Show
Features
1、Clear scale printing, black characters on white background, red pointer, apparent color contrast, clear display.
2、Terminal wiring is simple and convenient, embedded installation, beautiful and generous.
3、Mainly used to directly measure the current in the electrical circuit, simple structure.
4、Convenient installation, clear scale, beautiful appearance and quality assurance.
5、Can be used in some power equipment and electrical instruments in the transmission and distribution system.
Package List
1 x Pointer DC Ammeter
4 x Stainless Steel Nut
4 x Spring Pad
6 x Flat Pad
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 2.73 Inch |
| Height | 2.34 Inch |
| Length | 2.73 Inch |
