85C1 DC 0~500UA ABS Pointer Ammeter Ampere Meter Panel High Accuracy Current Meter

Item Type: DC Pointer Ammeter
Material: ABS
Product Total Size: Approx. 63 x 58 x 56mm/2.5 x 2.3 x 2.2in
Model: 85C1-A DC 0~500UA
Accuracy Grade: ±2.5%
Insulation Resistance: >20MΩ/DC500V
Damping Time: <4S
Product Use: Measuring Circuit Current
Installation Method: Suitable for Vertical Installation (Except for Special Regulations)
Storage Temperature: -40℃~70℃
Working Temperature: -20℃~40℃, Relative Humidity≤85%

Features

1、It can be used to directly measure the current in the circuit on some power equipment in the power transmission and distribution system.
2、The scales are clear, the dial is silk‑screened scales, black characters on a white background, red pointers, and vivid color contrast.
3、Easy installation, with installation accessories, embedded installation method, beautiful and generous.
4、The pointer type ammeter is simple in structure, convenient in wiring terminals and easy in operation.
5、The shell is made of high‑quality ABS material, which is not easy to be damaged and the quality is guaranteed.

Package List

1 x DC Pointer Ammeter

4 x Stainless Steel Nut

4 x Spring Washer

6 x Flat Washer
