AC 2 Way 3 Wire Brass Motorized Ball Valve Electrical Valve DN40 G1-1/2"

This product is composed of a brass valve and an actuator, the
actuator is driven by a synchronous motor and has a built-in limit switch that will
de-energize the valve when it is opened or closed, safe and energy-saving. It is
applicable for the fan coil and water control system of air conditioner.
Features:
1. Forged by high quality brass, the ball valve is durable and
reliable.
2. Built-in actuator de-energize the valve when it is opened or closed,
safe and energy-saving.
3. The product occupies little external space and can be installed close
to the wall.
4. Precision structure, tight close, no leakage.

Specification:
Valve Material: Brass
Power: 6W
Thread: DN40 G1-1/2"
Suitable Medium: Cold water, hot water or 60% ethanol
Medium Temperature: 2~95℃
Nominal Pressure: 1.6MPa
Allowable Pressure Difference: 1MPa
Wiring Method:
Double Color Wire(SR): Neutral line,
Blue Wire (BL): Open valve,
Brown Wire (BR): Close valve
Weight: 1018g/35.9oz

Package list:
1 * Motorized Ball Valve

Features

1、Forged by high quality brass, the ball valve is durable and reliable.
2、Built-in actuator de-energize the valve whien it is opened or closed, safe and energy-saving.
3、The product occupies little external space and can be installed close to the wall.
4、Precision structure, tight close, no leakage.
5、Mainly used for the fan coil and water control system of air conditioner.
