AC Current Transformer Current Sensor Module 0-5A 3p/4p Interface

Features:

Specification:
Transformation coefficient: Max 1000:1
Input current: Max. 5A
Output current: Max. 5mA
Sampling resistor: Max. 200Ω
Working frequency: Max.20-20000 Hz
Working temperature: -55~85 ℃
Dielectric strength: 6 KAC/1min
Interface: 3PIN/4pin
Weight: Approx.10g/0.4oz
Package list:
1* Current Sensor Module

Features

1、Analog Current Meter Module. Transformer can only sense AC
2、This electricity sensor is based on TA12-100 current transformer, which can transform AC signals of large current into small amplitude signals.
3、3-wire electronic block interface, input 5V - GND. S pin is the output analog voltage value.
4、You can use jumpers to select the parallel output of the output to adjust the range of analog values that are output
5、On-board 3P and 4P connecting interface for current signal output can be easily connected with your MCU development board
