BEM Solid State Relay DC Control AC Flame Retardant Industrial Grade Electrical EquipmentH3300Z

Condition: 100% Brand New
Item Type: Solid State Relay
Material: Plastic
Color: As picture shown
Brand: BEM
Input Current: 4-32V DCOptional Model: H3250Z, H3300Z, H3350Z, H3400Z
H3400Z110V220V380V
Resistive
Load22KW44KW76KW
Inductive
Load7.3KW14.6KW25.3KW
Capacitive
Load4.4KW8.8KW15.2KW
Maximum Load400A
Weight (Approx.)0.277 KG/0.6lb
H3350Z110V220V380V
Resistive
Load19.2KW38.5KW66.5KW
Inductive
Load6.4KW12.8KW22.5KW
Capacitive
Load3.85KW7.7KW13.3KW
Maximum Load350A
Weight (Approx.)0.281KG/0.6lb
H3300Z110V220V380V
Resistive
Load16.5KW33KW57KW
Inductive
Load5.5KW11KW19KW
Capacitive
Load3.3KW6.6KW11.4KW
Maximum Load300A
Weight (Approx.)0.272KG/0.6lb
H3250Z110V220V380V
Resistive
Load13.7KW27.5KW47.5KW
Inductive
Load4.5KW9.1KW15.8KW
Capacitive
Load2.75KW5.5KW9.5KW
Maximum Load250A
Weight (Approx.)0.272KG/0.6lb

Features

1、Superior plastic material, high temperature resistant and flame retardant, good insulation performance.
2、Highly sensitive, fast breaking and anti‑breakdown, safe and dependable.
3、Adopt for HSDQ SCR chip, making it has stable and professional performance.
4、4‑32V DC input current and 30‑480V AC control voltage, reliable in use.
5、Built to meet standard specification, strictly follow factory quality control.
