Product Overview
Features:
Specification:
Model: BEM08-02-NK
Output Form & Status: NPN NO
Detection Distance: 2mm
Detection Object: Iron/magnetic metal (Detection distance of non-magnetic metal will reduce)
Hole Size: 8mm
Cable Length: 1.75m
Protection Rating: IP67
Housing Material: Copper nickel plating
Control Output: ≤200mA
Current Consumption: ≤10mA
Response Frequency: 500Hz
Indicator Light: Action indicator (red LED)
Insulation Resistance: >50MΩ (500VDC megohm reference)
Vibration Resistance: 10-55Hz (cycle one minute) amplitude 1mm X, Y, Z 2 hours in each direction
Impact Resistance: 500m/s2 (50G) X, Y, Z 3 times in all directions
Working Environment: -25~+70℃, 35-95%RH
Storage Environment: -30~+80℃, 35-95%RH
Protection Circuit: Built-in Surge Protection Circuit, Power Reverse Polarity Protection Circuit, Over Current Protection Circuit
Package List:
1 x Inductive Proximity Switch
2 x Nuts
1 x Metal Washer
Specification:
Model: BEM08-02-NK
Output Form & Status: NPN NO
Detection Distance: 2mm
Detection Object: Iron/magnetic metal (Detection distance of non-magnetic metal will reduce)
Hole Size: 8mm
Cable Length: 1.75m
Protection Rating: IP67
Housing Material: Copper nickel plating
Control Output: ≤200mA
Current Consumption: ≤10mA
Response Frequency: 500Hz
Indicator Light: Action indicator (red LED)
Insulation Resistance: >50MΩ (500VDC megohm reference)
Vibration Resistance: 10-55Hz (cycle one minute) amplitude 1mm X, Y, Z 2 hours in each direction
Impact Resistance: 500m/s2 (50G) X, Y, Z 3 times in all directions
Working Environment: -25~+70℃, 35-95%RH
Storage Environment: -30~+80℃, 35-95%RH
Protection Circuit: Built-in Surge Protection Circuit, Power Reverse Polarity Protection Circuit, Over Current Protection Circuit
Package List:
1 x Inductive Proximity Switch
2 x Nuts
1 x Metal Washer
Features
1、This is an inductive proximity switch sensor with 2mm detection distance.
2、When the object approaches the sensing area of the switch, the switch can quickly emit electrical commands without contact or pressure required, accurately reflecting the position of the moving object.
3、Quick response, high reliability, strong anti-interference capability.
4、Built-in multiple protection circuits for safety use.
5、Widely used in automatic control system for detecting, positioning control, counting, automatic protection and more.
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 1.56 Inch |
| Height | 1.56 Inch |
| Length | 3.12 Inch |
