Product Overview
Material: Iron, Copper, Plastic
Color: Black Green
540 Brushed Motor:
T Number: 80T
Length: Approx.53mm / 2.1in(Without Shaft)
Diameter: Approx.36mm / 1.4in
Shaft Length: Approx.12mm / 0.5in
Shaft Diameter: Approx.3.175mm / 0.13in
65A Brushed ESC:
Battery Support: 5-9Ni MH, 4-6Ni Cd (4.8V-7.2V)
Li Ion Battery 2-3S: 7.4V-11.1V
Current Parameters: Forward 320A, Reverse 160A, Brake 270A
BEC Output: 5V 2A (Power Supply For Receiver And Servo)
Function: Forward And Brake; Forward And Brake And Backward
Product Size: Approx.43 x 30 x 28mm / 1.7 x 1.2 x 1.1in (Without Cable)
Suitable For Models: for Axial for Scx10 90046, for Traxxas, for D90, for HSP for Redcat, for Tamiya for HPI Installation
Features
1、Small Friction: High purity copper winding maximizes efficiency. High strength magnet, low friction, low noise, accurate balance of rotor, smoothness to improve reliability and maximum speed.
2、Strong Anti Interference Ability: The 540 brush motor has large torsion, exquisite circuit design, strong anti interference ability, two way bearing, strong magnetic force, low calorific value and high power.
3、Multi Protection: Multi protection function, strong current resistance and good heat dissipation. With long service life, it is a good choice for remote control car replacement.
4、Overheating Protection: Overheating protection. When the temperature reaches 100°C, the output power will decrease and the speed will slow down. When the temperature drops, the speed will return to normal.
5、Waterproof ESC: 65A waterproof ESC is compatible with brush motor, with white plug for Tamiya, which has high power and can be used for different types of RC ships or RC cars.
Package List
1 x 540 Brush Motor
1 x 65A ESC
1 x User Manual
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.51 Inch |
| Height | 1.95 Inch |
| Length | 4.68 Inch |
