Product Overview
Features:
Specifications:
Input voltage: DC10-55V
Maximum current: 60A
Continuous current: 40A
Speed control type: flow control
Speed control: potentiometer (linear)
Support motor: DC brush motor
CW and CCW rotation: support
Speed regulation range: 0-100%
Connection type: terminal
Knob specification: 100K (with switch)
Type of connection: barrier terminal
Weight: 295g
Package included:
1 x Motor Speed Controller
Note:
1. The digital display is the motor full speed percentage 0-100, non-motor actual speed
Specifications:
Input voltage: DC10-55V
Maximum current: 60A
Continuous current: 40A
Speed control type: flow control
Speed control: potentiometer (linear)
Support motor: DC brush motor
CW and CCW rotation: support
Speed regulation range: 0-100%
Connection type: terminal
Knob specification: 100K (with switch)
Type of connection: barrier terminal
Weight: 295g
Package included:
1 x Motor Speed Controller
Note:
1. The digital display is the motor full speed percentage 0-100, non-motor actual speed
Features
1、100% brand new and high quality
2、This product is 40A high power Speed Controller, mainly used for controlling the DC motor Speed
3、The built-in cooling fan, make it not easy to fever, ensure high efficient work
4、Digital LED display of 0-100% speed percentage
5、This motor speed controller support DC motor CW and CCW rotation
Package Weight and Dimension
| Weight | 0.68 lb |
| Width | 3.9 Inch |
| Height | 1.95 Inch |
| Length | 7.02 Inch |
