Fiber Optic Power Meter for APC Connector Color LCD Screen Handheld PON Network Online Testing Device

Item Type: PON Power Meter
Measurement Uncertainty: ≤0.5dB
Insertion Loss: ≤1.5dB
Detector Type: For InGaAs
Display Resolution: 0.1dB
Fiber Type: SM 9/125μm
Threshold Settings: 10 Sets
Fiber Connector: For APC (interchangeable SC, ST)
Display: Color LCD Screen
Data Storage: 10 records
Data Interface: Micro USB
Power Supply: 3 x 1.5V AA Battery (not included)
Battery Life: Standby >20 hours
Operating Temperature: -10-+50℃
Storage Temperature: -40-70℃
Relative Humidity: 0-95% non condensing

Features

1、Accurate Measurement: This PON power meter provides accurate power measurement at wavelengths of 1310nm, 1490nm, and 1550nm, with high isolation.
2、User Friendly Design: Equipped with a color LCD screen, this power meter provides clear and easy to read results, also allows for threshold settings and data storage of up to 10 records.
3、Versatile Compatibility: The PON power meter uses for APC fiber connector, can be easily interchangeable with SC or ST connector, suitable for different fiber optic setups.
4、Good Performance: The optical power meter adopts sensitive chip with sturdy internal structure, high accuracy, optional switching display, and automatic power off function.
5、Multiple Usages: This handheld PON optical testing device can help check the performance of cables, calculate relative power loss, locate faults, and troubleshoot them.

Package List

1 x Optical Power Meter
3 x Adapter Heads
1 x Storage Bag
3 x Accessories
1 x Cable Tie
