Product Overview
Item Type: Flowmeter
Material: UPVC
Data Transmission: RS485
Measurement Accuracy: ±3%
Working Voltage: 10-30VDC
Operating Current: 60mA Maximum (30VDC)
Measuring Liquid: Water or other chemical liquid
Working Pressure: 5kg/cm²
Response Time: Real time
Protection Class: IP65
Working Environment Temperature: -10℃~70℃
Instantaneous Flow Meter Settable Range (LPM): 0-999.99
Total Flow Meter Settable Range (FTM): 0-999999
Instantaneous Flow Control Output Method: NPN (150mA Maximum)
Total Flow Control Output Method: NPN (150mA Maximum)
Cable: Approx. 50cm / 19.7in
Material: UPVC
Data Transmission: RS485
Measurement Accuracy: ±3%
Working Voltage: 10-30VDC
Operating Current: 60mA Maximum (30VDC)
Measuring Liquid: Water or other chemical liquid
Working Pressure: 5kg/cm²
Response Time: Real time
Protection Class: IP65
Working Environment Temperature: -10℃~70℃
Instantaneous Flow Meter Settable Range (LPM): 0-999.99
Total Flow Meter Settable Range (FTM): 0-999999
Instantaneous Flow Control Output Method: NPN (150mA Maximum)
Total Flow Control Output Method: NPN (150mA Maximum)
Cable: Approx. 50cm / 19.7in
Features
1、±3% ACCURACY MEASUREMENT: High accuracy and large flow, accurate measurement, meet the accuracy requirements, which can reach ±3%
2、OXIDATION RESISTANT UPVC: Flowmeter is made of good quality UPVC material, oxidation resistant and more durable, you can use with confidence
3、WIDE RANGE OF APPLICATIONS: Mainly used in petrochemical, residential flow control, water plants, farmland and garden irrigation, etc.
4、GOOD PROTECTION: Support RS485 data transmission, IP65 protection grade, working environment temperature from -10℃~70℃
5、5KG/CM² WORKING PRESSURE: Measuring liquids include water or other chemical liquids, working pressure for 5kg/cm², realize real time response
Package List
1 x Flowmeter
Package Weight and Dimension
| Weight | 0.88 lb |
| Width | 3.51 Inch |
| Height | 2.34 Inch |
| Length | 7.02 Inch |
