Product Overview
Package List
1 * 2-in-1 Oscilloscope
1 * Clip Probe
1 * Test Probe
1 * Power Adapter
1 * USB Charging Cable
1 * Multimeter Probe
1 * Storage Bag
| Model | Hantek2C42 | |||||||
| Oscilloscope Mode | ||||||||
| Bandwidth | 40MHz | |||||||
| Channel | 2CH+DMM | |||||||
| Horizontal | ||||||||
| Sample Rate Range | 250MSa/s(Single-channel), 125MSa/s(Dual-channel) | |||||||
| Waveform Interpolation | (sin x)/x | |||||||
| Record Length | Max. 6K for single-channel; 3K samples per dual-channel | |||||||
| SEC/DIV Range | 5ns/div~500s/div 1, 2, 5 sequence | |||||||
| Vertical | ||||||||
| A/D Converter | ||||||||
| Weight | 2.81 lb |
| Width | 7.41 Inch |
| Height | 3.9 Inch |
| Length | 9.75 Inch |
