Product Overview
Material: 304 stainless steel, 316L stainless steel, fluororubber, NBR
Accuracy: ±0.5% F.S
Stability: <0.5% F.S per year
Operating Temperature: -20℃ to +85℃
Storage Temperature: -40℃ to +100℃
Measured Medium: Gas or liquid compatible with 304 and 316L stainless steel, fluororubber or nitrile rubber
Electrical Performance: Three wire system
Output Signal: 0.5-4.5V
Power Supply: 4.75-5.25VDC
Electrical Connection: M14 waterproof output line
Protection Grade: IP68
Pressure Interface: M20x1.5, throw in type
Features
1、INTEGRATED CHIP: Using integrated chip, with strong anti interference, high sensitivity, high measurement accuracy and great stability.
2、STAINLESS STEEL MATERIAL: The body and diaphragm are made of stainless steel, resistant to impact, rust and corrosion, can be used for acidic and alkaline liquids.
3、FINE MADE: This transmitter is precisely designed with 3mm pressure hole, 45 degree bevel design, making the measurement more accurate.
4、IP68 PROTECTION: This liquid level sensor is IP68 grade waterproof and dustproof, not afraid of deep water area, more reliable to use.
5、WIDE PURPOSE: This level transmitter is applicable for fire protection water tank, rivers and lakes, acid alkali tank, hydraulic test, etc.
Package List
1 x Liquid Level Transmitter
1 x Manual
Package Weight and Dimension
| Weight | 2.04 lb |
| Width | 11.7 Inch |
| Height | 5.46 Inch |
| Length | 11.7 Inch |
