Microwave Sensor Switches Radar Induction Control Equipment TDL-9961J 3.7GHz AC85‑

Item Type: Microwave Sensor Switches
Product Model: TDL-9961J
Quiescent Current: 30uA
Load Power: 10A
Load Capacity: Control incandescent lamp≤1000W, energy-saving lamp/fluorescent lamp≤400W, LED lamp category≤200W
Microwave Frequency: 3.7GHz
Sensing Angle: 360 degrees
Delay Time: 1 second to 330 seconds (adjustable)
Light Control Range: 7～500lm (adjustable)
Induction Distance: Approx. 15meter / 49.2ft
Working Temperature: -20 ℃～+50 ℃
Diameter: Approx.100mm / 3.9in
Thickness: Approx. 30mm / 1.2in
Size: Approx. 56mm / 2.2in

Features

1、Good stability, strong anti‑interference, wide sensing range and high sensitivity.
2、The control signal output delay time is adjustable, accurate and good performance.
3、External photodiode, not working during the day (adjustable to work during the day).
4、Sensing and penetrating power is strong, can penetrate wood, glass, wall, etc., metal can not penetrate.
5、When people come, the lights are on and the delay time is when people walk.

Package List

1 x Switch Sensor

1 Package Accessories(3 parts)

1 x User Manual
