RC Electric Speed Controller 30A with T Plug Long Wire RC Brushless ESC for Fixed Wing Aircraft Upgrade

Item Type: RC Electric Speed Controller
Material: Electronic components
Gross Weight: 30g/1.1oz
Color: Black
Continuous Current: 30A
Peak Current: 35A-40A, 10 seconds
Voltage Range: 4V-16V
Applicable Battery: 2-4S lipo
BCE Output: 5V 2A
Power Plug: T plug
Motor Plug: 3.5mm golden banana head
Applicable: Fixed wing aircraft for T rex 450, for V2 helicopter, for F450 small quad rotor UAV, etc

Features

1、Safety Power on Function: when power on, no matter where the throttle rocker is, the motor will not start immediately to avoid injury.
2、Throttle Stroke Calibration Function: The throttle stroke calibration function can adapt to the difference of throttle stroke of different remote controllers and improve the linearity of throttle response.
3、Delicate Speed Control: The RC electric speed controller has a fluent and delicate speed control feel and first class speed regulation linearity.
4、Low Voltage Protection Mode: With low voltage protection mode, when you reduce the power or turn off the output, the default is to reduce the power.
5、Good Anti Interference Ability: The power input terminal adopts the electrolytic capacitor with ultra low impedance and large capacity, which greatly improves the anti interference ability.

Package List

1 x RC Electric Speed Controller

1 x Manual
