Product Overview
Item Type: RF Power Amplifier
Material: Printed Circuit Board
Working Frequency: 380 -- 450MHz
Input Power: 0.1W (20dBm)
Maximum Output: 2.5W (34dbm) - 5.0V power supply, 5.0w (37dbm) - 7.2V power supply
Working Current: 1 - 2A (determined by output power)
RF Connector: Standard SMA female
Material: Printed Circuit Board
Working Frequency: 380 -- 450MHz
Input Power: 0.1W (20dBm)
Maximum Output: 2.5W (34dbm) - 5.0V power supply, 5.0w (37dbm) - 7.2V power supply
Working Current: 1 - 2A (determined by output power)
RF Connector: Standard SMA female
Features
1、Possess large area heat dissipation, which can guarantee run for a longer time
2、Printed circuit board possess 1.5 oz copper thickness and 1.6mm thick double‑sided board
3、Full tinning process guarantee good passing performance of large and small currents
4、One - piece molding without burr, come with smooth surface and simple installation
5、High quality RF power amplifier module possess stable structure and high performance
Package List
1 x RF Power Amplifier
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 2.73 Inch |
| Height | 1.17 Inch |
| Length | 3.9 Inch |
