Stepper Motor Module Simple Reliable PWM Pulse Signal Generator Modules DC 24V 12V

Item Type: Stepper Motor Module
Describe:
1. This module is a pulse generation module, which provides control signals to the stepper driver.
In order to control the stepper motor, a driver must be equipped.
2. This simple controller + stepper motor + stepper motor + DC power supply can form a simple control platform.
3. The controller has 3 kinds of low frequency signals of high 5.4k-160khz, middle 540-16.6khz, and low 80-2.4khz, which can be used to select jumpers.
4. Can generate pulse signal or PWM signal, and can choose jumper.
5. Measuring Frequency: PUL and common cathode.
Different stepper drives may be marked with different names
EN = ENA = FREE Enabled
PUL = PULS = CLK Pulse
DIR = CW = CWW Direction

Features

1、Provide Control Signal: This module is a pulse generation module that provides control signals to the stepper drive.
2、Simple Control Platform: This simple controller + stepper motor + stepper motor + DC power supply can form a simple control platform.
3、3 Kinds of Low Frequency Signals: The controller has high 5.4k‑160khz, middle 540‑16.6khz, low 80‑2.4khz, a total of 3 low frequency signals can be used to select jumpers.
4、Basic Specifications: The controller module can generate pulse signals or PWM signals, with optional jumpers.
5、Measuring Frequency: This is a controller module whose measuring frequency is PUL and common cathode.

Package List

1 x Relay Module
