Product Overview
Item Type: Signal Generator Module
Material: PCB
Power Supply: DC 12V 24V
Current: 4-20mA
Total Power: <1W
Output Load Impedance: 0-350Ω (DC12V); 0-800Ω (DC 24V)
Material: PCB
Power Supply: DC 12V 24V
Current: 4-20mA
Total Power: <1W
Output Load Impedance: 0-350Ω (DC12V); 0-800Ω (DC 24V)
Features
1、Knob Operation: Easy to use and connect, good performance. Knob operation to adjust response output without delay.
2、Polarity Protection: The power port is polarity protected and will not damage components that are opposite to the power supply.
3、Parameters: Supply voltage: DC 12V or 24V (tolerance ±25%), total power <1W. Output load impedance range: 0‑350Ω (DC12V); 0‑800Ω (DC 24V).
4、Test: To test whether the output is normal, you can use a multimeter to short circuit the "4‑20mA output" terminal.
5、Applicability: Can be used for signal source, valve adjustment, output meter test, LED test, analog transducer.
Package List
1 x Signal Generator Module
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.12 Inch |
| Height | 1.17 Inch |
| Length | 3.9 Inch |
