Product Overview
Item Type: Temperature Humidity Sensor Module
Model: GY-BMP280-5V
Material: PCB board
Application: Temperature, humidity, atmospheric pressure sensing
Air Pressure Measurement Range: 300-1100 hPa
Air Pressure Measurement Accuracy: ±1.0 hPa
Absolute Accuracy of Pressure Measurement: ±1.0 hPa
Temperature Measurement Range: -40℃~85℃
Temperature Measurement Accuracy: ±1
Current Consumption: 0.6 mA
Interface: I2C and SPI (compatible with 3, 4 wire SPI interface)
Features: Can be used as an altimeter with an accuracy of ±1meter
Model: GY-BMP280-5V
Material: PCB board
Application: Temperature, humidity, atmospheric pressure sensing
Air Pressure Measurement Range: 300-1100 hPa
Air Pressure Measurement Accuracy: ±1.0 hPa
Absolute Accuracy of Pressure Measurement: ±1.0 hPa
Temperature Measurement Range: -40℃~85℃
Temperature Measurement Accuracy: ±1
Current Consumption: 0.6 mA
Interface: I2C and SPI (compatible with 3, 4 wire SPI interface)
Features: Can be used as an altimeter with an accuracy of ±1meter
Features
1、INTUITIVE CIRCUIT PCB BOARD: Select good quality PCB board production, the circuit is simple, intuitive and easy to understand
2、ACCURATE AND FAST: This sensor module bring accurate measuring point, stable and fast transmission speed, low power consumption
3、PORTABLE TO CARRY AND USE: Atmospheric pressure sensor module is small and portable, easy to install without taking up space
4、WIDE APPLICATIONS: This module can be used for temperature, humidity, atmospheric pressure sensing, versatile and practical
5、LOW POWER CONSUMPTION: The power supply voltage is 5V, current consumption for 0.6mA, and the interface adopts I2C and SPI, which can be used as an altimeter
Package List
1 x Temperature Humidity Sensor Module
1 x Pin Header
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 0.78 Inch |
| Height | 0.39 Inch |
| Length | 0.78 Inch |
