4Pcs Universal Rotary Switch Reverse Combination Switches HZ10D-10/3 220-380V 10A

Item Type: Universal Rotary Switch
Material: PC, silver alloy, copper
Level: 0-1-0-1 (reverse type)
Reset Method: Positioning type
Rated Current (Ie): 10A
Mechanical Life: 1 million times, operating frequency is 300 times/hour
Uses: The product has a wide range of uses, which can be used as circuit control switches, test equipment switches, motor control switches, master control switches, and transfer switches for electric welding machines.
A1=Approx. 65mm / 2.6in
A2=Approx. 43mm / 1.7in
H=Approx. 74mm / 2.9in
M=Approx. 43mm / 1.7in
D=ΦApprox. 6mm / 0.2in
C=Approx. 58mm / 2.3in
B1=Approx. 55mm / 2.2in
B2=Approx. 74mm / 2.9in
S=Approx. 5mm / 0.2in

Features

1、The product has fine and beautiful workmanship, flexible handle and small size.
2、The switch adopts silver alloy contacts, which has good conductivity and makes the switch work more stable.
3、The product is easy to install, with stable operation and has long service life.
4、Using PC material with good insulation performance, flame retardant and high temperature resistance.
5、Can be used as circuit control switch, test equipment switch, motor control switch and transfer switch for electric welding machine.

Package List

4 x Universal Rotary Switch
