Product Overview
Item Type: Amplifier Module
Material: PCB
Power Supply Voltage: 12V DC (Typical Current Value 75MA)
Gain: 19.5DB
Input And Output Impedance: 50Ω
Maximum Output Power: 19.5dBm (At 6VPP\50Ω Load)
Input Signal: <=0DBM (The output signal is already distorted when the input is greater than 0dBm)
Bandwidth: 1MHz to 3GHz (The gain is different under different frequencies)
Noise Figure: 2dB (Measured at 1.5GHz)
Point Frequency Method Gain:
F=15.2MHZ: GAIN=17.99DB
F=345.2MHZ: GAIN=19.55DB
F=945.2MHZ: GAIN=18.09DB
F=1.500GHZ: GAIN=16.16DB
F=1.955GHZ: GAIN=15.77DB
F=2.295GHZ: GAIN=14.11DB
F=2.610GHZ: GAIN=13.60DB
F=2.895MHZ: GAIN=12.56DB
Material: PCB
Power Supply Voltage: 12V DC (Typical Current Value 75MA)
Gain: 19.5DB
Input And Output Impedance: 50Ω
Maximum Output Power: 19.5dBm (At 6VPP\50Ω Load)
Input Signal: <=0DBM (The output signal is already distorted when the input is greater than 0dBm)
Bandwidth: 1MHz to 3GHz (The gain is different under different frequencies)
Noise Figure: 2dB (Measured at 1.5GHz)
Point Frequency Method Gain:
F=15.2MHZ: GAIN=17.99DB
F=345.2MHZ: GAIN=19.55DB
F=945.2MHZ: GAIN=18.09DB
F=1.500GHZ: GAIN=16.16DB
F=1.955GHZ: GAIN=15.77DB
F=2.295GHZ: GAIN=14.11DB
F=2.610GHZ: GAIN=13.60DB
F=2.895MHZ: GAIN=12.56DB
Features
1、Low noise amplifier radio frequency amplifier module, with shell shielding, running more smoothly.
2、50Ω input and output impedance, fixed impedance, more stable operation, good performance.
3、PCB adopts 1.6mm thick double sided board, and the whole process of spraying tin to ensure good passing performance of large and small currents.
4、12V DC supply voltage, 19.5DB gain, 1MHz to 3GHz bandwidth, 19.5dBm maximum output power.
5、Small in size and light in weight, convenient to carry and use at any time, very convenient and practical.
Package List
1 x Amplifier Module
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 2.34 Inch |
| Height | 0.78 Inch |
| Length | 3.51 Inch |
