Product Overview
Material: Aluminum Alloy
Processor: DSP
Built In Memory: 512MB
Display: 3 Inch Monochrome Screen
Linkage Axes: 3 Axes
Control Signal: Differential Signal
Drive System: Stepper, Servo Motor
Minimum Input Unit: 0.001mm
Power Down Protection Function: Support
Breakpoint Processing Function: Support
Manual Mode: Continuous, Spot, Distance
Interpolation Mode: Linear, Circular Arc
Soft And Hard Limit: Support
Maximum Pulse Frequency: 1MHz
Password Protection: Support
Features
1、3 Axes Motion Control Mode: This motion control system adopts X, Y, Z 3 axes motion control mode, supports rotary axes (C axes) control, and can realize switching between rotary machining and plane machining.
2、Multi Input And Output Points Control Method: This motion control system adopts multi input and output points control method, and the standard input and output signal nodes are equipped with 8 input and output signals each.
3、Various Software Supported: This motion control system supports standard G code, PLT format commands, and domestic and foreign mainstream CAM software, such as for Type3, for Artcam, for UG, for Pro E, for MasterCAM, for Cimatron, for Wentai and other software.
4、Power Down Protection Function: This motion control system is equipped with power down protection function, the system automatically saves the current machining information (file name, current machining line number, machining speed, spindle gear) at the moment of machining power outage, and after powering up again and completing the action of going back to the origin of the machine tool, the system automatically prompts the user to resume the machining before the power outage, which makes the machining operation more humanized.
5、Built In 512M Memory: This motion control system has a built in 512M memory, comes with a USB communication port for efficient file transfer, and can directly read files from USB flash disks and card readers, plug and play.
Package List
1 x Control Handle
1 x Controller
2 x Connection Cable
1 x Manual
Package Weight and Dimension
| Weight | 3.33 lb |
| Width | 7.02 Inch |
| Height | 3.9 Inch |
| Length | 8.97 Inch |
