Product Overview
Item Type: Frequency Generator
Model: XY-PWM
Working Voltage: DC 3.3V-30V
Frequency Range: 1Hz~150KHz
Frequency Accuracy: 2%
Duty Cycle Range: 0.00% - 100.0%
Output Current: About 5-30mA
Output Amplitude: Same as input voltage.
Working Temperature: -20℃ ~ 70℃
Model: XY-PWM
Working Voltage: DC 3.3V-30V
Frequency Range: 1Hz~150KHz
Frequency Accuracy: 2%
Duty Cycle Range: 0.00% - 100.0%
Output Current: About 5-30mA
Output Amplitude: Same as input voltage.
Working Temperature: -20℃ ~ 70℃
Features
1、Clear Display: With LCD display, the current mode and parameters are clear at a glance, very clear, simple and practical.
2、Better Control: Supports key trigger control, high and low level trigger, and switching value control. Applicable to most occasion.
3、Automatic Data Storage: All parameters will be automatically saved after setting, so they will not be lost when shutting down.
4、Signal Generator: The signal generator is a device for generating electrical signals of various frequencies, square waves, pulses and output levels.
5、With 2 Modes: Supports two modes, PWM mode and PULSE mode. It is used as the signal source or excitation source for testing.
Package List
1 x Frequency Generator
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 1.95 Inch |
| Height | 1.17 Inch |
| Length | 3.51 Inch |
