Product Overview
Item Type: Linear Stage Trimming Platform
Model: RS60-L
Can be Realized: coarse adjustment 360 degrees, rotation precision adjustment ±5°
Material: Aluminum alloy (black anodized surface)
Table Diameter: Approx. 60mm / 2.4in
Moving Rail: Running-in installation
Drive Mode: Micrometer
Cursor Minimum Reading: Vernier Scale 0.1°
Micrometer Minimum Movement Reading: 0.015°
Load: 29.4N (3kgf)
Accuracy: 0.01m
Surface Runout: 0.02mm
Parallelism: 0.03mm
Scope of Application: Production machinery, testing equipment, optical experimental measurement, fine-tuning displacement, precision positioning, quantitative movement and so on.
Model: RS60-L
Can be Realized: coarse adjustment 360 degrees, rotation precision adjustment ±5°
Material: Aluminum alloy (black anodized surface)
Table Diameter: Approx. 60mm / 2.4in
Moving Rail: Running-in installation
Drive Mode: Micrometer
Cursor Minimum Reading: Vernier Scale 0.1°
Micrometer Minimum Movement Reading: 0.015°
Load: 29.4N (3kgf)
Accuracy: 0.01m
Surface Runout: 0.02mm
Parallelism: 0.03mm
Scope of Application: Production machinery, testing equipment, optical experimental measurement, fine-tuning displacement, precision positioning, quantitative movement and so on.
Features
1、Can be used in production machinery, testing equipment, optical experimental measurement, fine‑tuning displacement, precision positioning, quantitative movement and so on.
2、Main body aluminum alloy material, black anodized surface, scratch‑resistant, anti‑drop, anti‑corrosion.
3、Nickel plated locking screw, designed with counterbore, nickel plated fine adjustment knob, carbide side head, durable.
4、The driving method is a micrometer, which can be realized: manual coarse adjustment of 360 degrees, fine adjustment of rotation ± 5 degrees.
5、High precision, smooth movement, suitable to be built in other devices.
Package List
1 x Linear Stage Trimming Platform
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.51 Inch |
| Height | 1.56 Inch |
| Length | 5.85 Inch |
