Single Phase Energy Meter Bidirectional Metering 2P DIN Rail Mount KWh Electricity Usage Meter with RS485 Comm AC230V 5A

Item Type: Single Phase Energy Meter
Material: PC
Voltage: AC230V
Current: 5 (60) A
Accuracy Class: Class 1
Rated Frequency: 50/60Hz
Constant Pulse: 1600imp/KWh
Power Consumption: ≤2W, 10VA
Starting Current: 0.0041b
Operating Temperature: -20-55℃
Storage Temperature: -25-70℃
Relative Humidity: 5%-95%
Pulse Output Indicator Light: The indicator light blinks once to indicate synchronous pulse output

Features

1、Parameter Tracking: Single phase kWh energy meter, monitoring single phase active and reactive energy, current, voltage, power, frequency, and demand, and tracking energy consumption in real time.
2、RS485 and Pulse: This energy meter supports RS485 comm and provides 2 passive outputs. Pulse 1 can be configured as total, import, and export kWh, and pulse 2 has a fixed output of 1600imp/kWh.
3、Bidirectional Metering: This energy meter supports bidirectional metering, suitable for energy input, output, and performance monitoring, used for renewable energy applications such as solar energy and battery storage.
4、Installation and Display: Adopts standard 35mm DIN rail installation, with LCD backlight display, LED indicator pulse output, passive pulse output, and quick query of various parameters through buttons.
5、Wide Application: This single phase kWh meter provides accurate measurement, power consumption monitoring, and data collection, suitable for efficient performance monitoring or energy management in PV system.

Package List

1 x Energy Meter
1 x User Manual
